4.5" 1999-2006 GM 1500 4WD High Clearance Lift Kit
The BDS No Torsion Bar Drop System will make your 1999-2006 pickup look like a lifted 2007-2008 design. The torsion bars are mounted directly to the top of the lower a-arm eliminating the need to drop the torsion bar crossmember.
Integrated with our unique BDS High Clearance Lift System this 4-1/2 inch suspension lift kit offers more ground clearance than any comparable lift kit. The high arched crossmembers maximize ground clearance while creating improved operating geometry.
A front skid plate and differential skid plate are included to lock everything together as well as offer extreme off road protection and improved performance.
The rear is lifted with a single block to eliminate stacking.
This highly customizable kit gives you the choices you need to build your rig to your personal specifications. BDS granite or powder coat black finishes, gas shocks, dual steering stabilizers, and Glide-Ride Leaf Springs are just a few of the options and upgrades available for this suspension lift kit.
Tire & Wheel Combinations
- 33 inch x 12.50 inch w/16 x 8 and 4.5 inch back spacing
- 33 inch x 12.50 inch w/18 x 9 and 5 inch back spacing
- 33 inch x 12.50 inch w/20 x 9 and 5.75 inch back spacing
- Est. Installation: 8-10 hours
- Difficulty Level (easy 1 - 5 complicated): 4
BDS Suspension Lift Kit Warranty
All BDS Suspension lift kits come with the security of knowing you purchased the finest lift kit in the aftermarket suspension industry. We back our commitment to engineering reliable, quality 4x4 off-road Jeep and truck suspension products with our unique 'No BS Hardcore Lifetime Warranty'.
If you are the original purchaser of any BDS lift kit and it breaks, we will give you a new part. Period.
|Manufacturer Part Number||181H|
|Model||1500 Pickup, 1/2 ton Pickup, K10 Pickup, K1500 Pickup, 1500 Silverado, 1500 Sierra, Suburban 1500, 1/2 ton Suburban, Blazer, Jimmy, K5|
|Lift Height||4.5 inch|
|Notes||If equipped with stock 17 inch wheels then must replace with 17 inch or larger aftermarket wheels.
Requires frame bracket modification and differential mount modification as well as minor welding.
Rear leaf springs are not included; lift is achieved via blocks and add-a-leafs.
Special tool required to unload/load torsion bars.
Will not fit Heavy Duty models.
