After seeing how great the ReadyLIFT 4.0" SST Lift Kit for the Silverado truck is, customers have asked for a similar kit for the GM SUVs and SUTs. In our continued effort to give customers the quality lift products they want our research and development has engineered the only 4.0" completely bolt-on lift kit on the market today. We call the 69-3495 4.0" SST Lift Kit System our "stage three" kit for the late model GM SUVs and SUTs.
The 69-3495 4.0" SST Lift Kit is the result of over six months of extensive product development followed by rigorous on and off road testing. ReadyLIFT's goal is to provide a true 4.0" lift kit that is completely bolt-on; no drilling, cutting or welding required. This system significantly increases ground clearance while allowing for tire sizes up to 33" tire on an aftermarket wheel. The most common tire size for this application is 33x12.50 (max). 22x9.5 with 5.5" backspacing requires no fender modifications. 17x9 +0 offset on a 285/70R17 will fit with no rubbing. With a 295/70r17 minor trimming/modification required. Note: This kit is designed for use with aftermarket wheels.
The ReadyLIFT 4.0" SST Lift Kit will raise the SUVs 4.0" in front thanks to tough trail-proven 4.0" powdercoated steel strut extensions that bolt directly to the top of the factory strut. Unlike some kits which require you to cut off your strut studs or break the top hat seal which are irreversible modifications, our rugged strut extensions require No Modifications to be made to the strut in order to install the extension. This guarantees the strut will maintain the factory integrity as well as drastically reducing installation time.
Two key products were developed to make achieving 4" of lift without modifications a possibly. At the heart of the system is our all-new 100% DOM tubular upper control arm. This new heavy-duty control arm features OEM-style ball joints pre-pressed into a strong crown that retains OEM geometry throughout the suspension cycle and doesn't require any modifications to the spindle. That means no drilling or machining to make the ball joints fit the spindle. The new control arms include 90-degree grease fittings to insure the life of the new polyurethane bushings.
The second important product that makes this kit possible is our Patent Pending CNC-machined 6061-T6 billet aluminum differential drop brackets. When raising the front suspension 4.0" the differential must be lowered to maintain front axle and CV angles. Readylift has engineered a differential drop system that cuts installation time in half compared to other similar kits. Unlike other differential drop brackets made from steel plate that bend and can cause CV failure, our CNC-machined brackets cannot ever bend, break or cause any driveline problems when using 4WD mode. That is guaranteed! Accompanying our patent pending differential drop brackets is a thick powdercoated plate steel skid plate that utilizes the factory attachment locations for ease of installation while providing tough differential protection when off roading.
To lift the rear of the GM coil spring-equipped SUVs, this lift system includes 3.0" powdercoated steel coil spring spacers. The strong coil spacers insert into and top of the factory spring which maintains the great factory ride! In addition a slight rake is helpful for towing or hauling. New longer and stronger rear sway bar end links and bump stop extensions are also provided to keep the rear suspension working properly.
Completing this great new lift system are a set of steel rear shock extensions. No need to replace your great-riding factory rear shocks with inferior aftermarket shocks. These new shock extension brackets keep the rear shocks in the factory mounting position which means your truck will ride great! And that's important!
Speaking of riding great, it is ReadyLIFT's philosophy that every lift system we manufacture should maintain and/or improve the factory ride when installed and used as recommended. The ReadyLift 69-3495 4.0" SST Lift Kit will make your SUV ride and handle great while providing the raised height you have been wanting. Every one of our test vehicle owners have commented on how great the truck rides both on and off road with this system.
Kit Includes: (2) Front SST 4.0" Strut Extensions, (2) Rear Shock Extension Brackets, (2) 3.0" Rear Coil Spring Spacers, (1) Steel Skid Plate, (2) CNC-Machined Differential Drop Brackets, (2) DOM Tubular Control Arms With Pre-Pressed Ball Joints, (2) Rear Bump Stop Extensions, (2) Rear Sway Bar End Links, (8) Polyurethane Greaseable Bushings, Instructions & All Necessary Hardware.
Like all ReadyLift products, the 69-3495 SST Lift Kit System is protected by our Limited Lifetime Warranty.
Features and Benefits:
- Keeps your factory ride - Guaranteed
- Will never wear, break or fail - Guaranteed
- Toughest finish – Guaranteed
- Safest way to lift - Guaranteed
- Direct bolt-on - No Cutting, Drilling or Welding Required
- Allows for up to 33" tires on aftermarket wheels
- Allows for up to a 22x9.5 wheel with 5.5" of backspacing
- 17x9 +0 offset on a 285/70R17 will fit with no rubbing. With a 295/70r17 minor trimming/modification required.
- Limited Lifetime Warranty
- Reduced Installation Time - Save An Hour Or More On Installation Compared to Other Similar Kits
