Chevy Stock Replacement Dana 44 Knuckle (passenger side) by Reid Racing

This Reid Racing D44002CR high-steer Chevy Dana 44 stock-replacement knuckle is designed with both a cast-in steering arm and a machined flat-top to be used in crossover-style and full high-steer applications using aftermarket bolt-on steering arms. The knuckle is machined with the Chevy/Jeep spindle bolt pattern and will accept “outers” from all open-knuckle Full-Size Jeep and Chevy Dana 44 & 10-Bolt solid axles from 1978 to 1991. The steering arm is tapered so that the tie rod installs from above just like the stock Dana 44 knuckles. The spindle bore is machined to fit the CTM u-joint without requiring the removal of the knuckle to install the axle shaft.

Top Features & Benefits

Installation Instructions
