5" 2004-2006 Jeep Wrangler LJ 4WD Pro LCG Long Arm Lift Kit by Teraflex

Brand: Teraflex | SKU: 1249585 / 1449585
From $4,588.99


free shipping truck FREE SHIPPING !!
on orders +$149, exclusions apply

- +
Expert Image
Trusted Experts Since 1994, Top Rated service
Got Questions? We can help!
888-452-2548
Top Rated service
Top Rated service
Top Rated service
Top Rated service
Top Rated service
Top Rated service
Product Description
More Information

The TeraFlex 1249575 LCG (Low Center-of-Gravity) long-arm suspension Systems for the Jeep Wrangler LJ are meticulously crafted for dedicated Jeep enthusiasts unwilling to compromise on-road comfort and control with their LJ. These comprehensive systems include all necessary components and feature LCG Long Arm Brackets for a seamless installation. At the forefront, the Pro LCG enhances the performance of the stock 5-link suspension setup with Teraflex adjustable LCG Long Control Arms & Brackets. Their Front Upper LCG Long Control Arms extend more than 9 inches beyond stock length, ensuring optimal performance. In the rear, the stock 5-link suspension and track bar are replaced by Teraflex adjustable Pro LCG Triangulated 4-Link Long Control Arm Suspension with Rear Axle Truss & Brackets. These rear upper brackets boast adjustable anti-squat tunability, allowing precise suspension adjustments.

The Teraflex adjustable LCG Long Control Arms effectively balance front caster and pinion angles and optimize rear pinion angles, anti-squat geometry, and tire position for vehicles with 3-5" lifts. For higher lifts, LCG Long Arm Brackets and 4-Link Rear Axle Truss reposition the frame-end control arm mounting points, reducing bushing stress during extreme droop and minimizing shock load transferred through the LCG Long Control Arms. The addition of the HD Adjustable Front Track Bar, Drop Pitman Arm (for 4"+ lifts), and Rear Upper Pro LCG Triangulated 4-Link Control Arms significantly enhances steering response, centers the axles to optimize vehicle roll center, and reduces body roll for unparalleled handling. This meticulous engineering results in improved suspension geometry, relaxed control arm angles, and superior ride quality and performance across all terrains. Furthermore, these systems restore the front and rear roll axis angles, minimizing brake dive and acceleration squat while reducing noise, vibration, and harshness (NVH).

Features and Benefits:

  • Low center of gravity with maximum ground clearance
  • 5" of suspension lift
  • 4-link rear upper geometry
  • Allows for the use of larger diameter tires
  • Eliminates rear track bar
  • Allows complete suspension travel for full articulation
  • Adjustable rear anti-squat bracketry for fine-tuning performance
  • Heavy-duty 1.75" DOM lower flex arm tubing
  • Front Upper LCG Long Control Arms are more than 9" longer than stock
  • Works with engine conversions (V6, V8, etc.)
  • Engineered to work with high-pinion aftermarket axles
  • Estimated install time: 23-24 hours
  • Made in USA
  • TeraFlex Limited Lifetime Warranty against defects
Important Notes1. REQUIRES aftermarket wheels w/ 4.5” backspacing or less – or Offset Wheel Adapters (# 1005200) for stock wheels – NOT INCLUDED.
2. 4”+ lifts require CV-style driveshaft and Short Shaft Slip Yoke Eliminator Kit (Extreme: # 4444400 or # 4444401). Highly recommended for 3” lift.
3. REQUIRES cutting/removal of factory control arm bracketry to install LCG Long Arm Brackets.
4. REQUIRES cutting and welding.
5. Alignment REQUIRED.
6. REQUIRES exhaust modification w/ custom cat-back exhaust.
7. 2003-2006 TJ Wrangler/Unlimited Rubicon REQUIRES BellyUp Compressor Mount Bracket Kit (# 4847400).
8. Contact TeraFlex customer service for details on other high-performance axles.
9. Pro LCG High Steer System (# 1849000) available separately. Recommended for 4”+ lifts.
10. REQUIRES longer shocks (NOT INCLUDED in base kit) – Falcon Series 3.0 Piggyback Shocks (# 04-01-30-400-304) or TeraFlex 9550 VSS Twin-Tube Shocks (# 1545270) recommended.
Vehicle Fitment
MakeJeep
ModelWrangler LJ
Year Fitment2006, 2005, 2004
2WD/4WD4WD
Tech Specs
ManufacturerTeraflex
Manufacturer Part Number1249585 / 1449585
Item Numbertfx_1249585-1449585
MPN(UPC)843885020486
Product LineLift Kits
Lift Height5 inch
SpecialFree Shipping!
