Jeep Wrangler TJ 1997-2006 Pro LCG Front Upper Long Arm kit w/brackets by Teraflex

Enhance your TJ Wrangler's suspension with the Front Upper Pro LCG Long Control Arm & Bracket Upgrade Kit. This system is designed to provide complete alignment adjustability and dependability, ensuring maximum performance on vehicles with 3-5" lifts. The kit can be seamlessly integrated into existing suspension lifts. The Pro LCG Long Arm Frame Brackets included in this kit reposition the frame-end control arm mounting points to nearly factory orientation, minimizing bushing stress during droop and reducing shock load transfer through the control arms on higher lifts. The CAD-engineered brackets and Triangulated 4-Link Rear Axle Truss offer exceptional strength and precision fitment, with 1/4"-thick steel brackets that are CNC laser cut and bent for accuracy.

The frame brackets utilize the factory belly pan skid plate bolt holes and are securely stitch welded. These components are identical to those in our premium Pro LCG and Enduro LCG Long Arm Suspension Systems, ensuring top-tier performance and durability. To achieve a full Pro LCG Long Arm Suspension System, combine this kit with the Rear Upper Pro LCG Triangulated 4-Link Long Control Arm & Bracket Upgrade Kit (TJ SWB: # 1444870 & LJ LWB: # 1444880) and the Lower LCG Long Control Arm & Bracket Upgrade Kit (TJ SWB: # 1447700 & LJ LWB: # 1447780).

Features and Benefits:

• Adjustable LCG Long Control Arms and Brackets ensure balanced front caster and pinion angles, optimize rear pinion angle, and fine-tune anti-squat geometry for proper suspension alignment on 3-5" lift kits.
• estimated install time: 6 hours
• LCG Long Control Arms are crafted from robust 1.25" x 0.25" (front upper) or 1.75" x 0.25" (lower, rear upper) wall DOM tube for exceptional strength.
• For higher lifts, LCG Long Arm Brackets and 4-Link Rear Axle Truss reposition frame-end control arm mounting points to relax suspension link angles, reducing bushing stress during extreme droop and shock load.
• LCG Long Arm Frame Brackets and Rear Axle Truss are gusseted and reinforced for superior strength with reduced NVH compared to other long arm kits.
• Constructed from CNC laser-cut and precision-bent 1/4" steel.
• Frame brackets use factory belly pan skid plate bolt holes and are stitch welded for secure installation.
• Pro LCG Triangulated 4-Link Frame Brackets and Rear Axle Truss convert the stock 5-link rear suspension to a triangulated 4-link setup for increased flex and eliminate interference with other components.
• Includes the same high-quality components found in our top-tier Pro LCG and Enduro LCG Long Arm Suspension Systems.
• Re-centers axles in the wheel well for proper suspension movement and can be used to increase wheelbase.
• Offers a full range of movement, ensuring no restriction on articulation or flex off-road.
• Features rebuildable joints for easy maintenance.
• Coated with a premium black e-dipped finish for superior durability and corrosion resistance.
• Backed by the TeraFlex Lifetime Warranty against defects.
