Sierra 1500 1999-2018 GMC 4wd - Rear 5" Lift Leaf Spring Set (w/bushings) by BDS Suspension

This BDS Suspension BDS001559 BDS Glide-Ride leaf spring set for the GMC Sierra 1500 is designed to reduce axle wrap and create a more controlled and stable feel when towing while adding 5 inches of lift height to the rear of the Silverado. These springs are covered by the BDS No Fine Print Warranty.

This special package includes (2) Leaf Springs, required bushings and sleeves.

Features and Benefits:

• 5 inch rear lift height
• Reduces axle wrap when used instead of rear lift blocks
• Maintains factory payload ratings
• Progressive leaf design designed for comfortable ride
• Polyurethane leaf spring bushings & steel sleeve included
• Eye to Eye Dimension: 61
• Free height Dimension: 10.75
• Eye to Center Pin Front: 32.5
• Eye to Center Pin Rear: 33.5
• Eye (F/R) Diameters: 1.5/1.5
• 5 Leafs Per Leaf Pack
• Width: 2.5"
• Center Pin Size: 7/16"

Package Contents

• (2) BDS001559 - BDS GlideRide Rear Leaf Springs
• (2) BDS071006 - BDS Leaf Spring Bushing & Sleeve Kit
