2.5" 2017-2019 Ford F250/F350 4WD (w/diesel engine) Fox Performance Elite CoilOver Radius Arm Lift Kit by BDS Suspension

Brand: BDS Suspension | SKU: 1543FPE

free shipping truck  FREE SHIPPING !!
on orders +$149, exclusions apply

- +
Expert Image
Trusted Experts Since 1994, Top Rated service
Got Questions? We can help!
Top Rated service
Top Rated service
Top Rated service
Top Rated service
Top Rated service
Top Rated service
Product Description
More Information

This BDS 1543FPE 2.5 inch coil-over lift kit is the ultimate premium suspension system for the Ford F250 / F350 Super Duty trucks.  Featuring Fox 2.5 Performance Elite Remote Reservior Coil-Overs with DSC (dual speed compression) adjustments to fine tune your ride with the turn of a dial.  These coil-overs replace the factory coil springs and are optimized for performance and ride comfort.  Heavy duty radius arms that use 1-3/4" OD -10GA DOM tubing with support gussets, these replacement arms are far superior to the factory stamped steel units. Featuring a high clearance design for extra ground clearance and are formed inward to allow for additional clearance of oversized tires. The arms correct the caster angle by bolting into the factory mounting points and reposition the front axle. The front axle remains centered with the use a of heavy duty adjustable track bar. Sway bar drop brackets keep the factory bar from binding.

In the rear the factory blocks are replaced by a pair of 4 inch lift blocks that feature integrated bump stop wings along with e-coated extended u-bolts.

Features and Benefits:

  • Ultimate Premium Suspension Lift Kit for Ford F250 / F350 models
  • Fox 2.5 Performance Elite Coil-overs replace factory coil springs
  • Coilovers feature DSC (dual speed compression) to allow fine tuning of your ride with the turn of a dial
  • 2.5 inch Pro-Ride Coil Springs feature smooth ride, top performance
  • Heavy Duty 1 3/4 inch tubular radius arms
  • High clearance arms for maximum clearance
  • Rear Fox 2.0 Performance Shocks
  • Allows use of up to 35 inch tires
  • Average Install Time: 5 hours
  • No Fine Print Lifetime Warranty
  • Factory Protection Plus
  • Fits a 35" x 12.50" w/17 x 9 tire and 4.5"-5" back spacing
  • Fits a 35" x 12.50" w/18 x 9 tire and 4.5"-5" back spacing
  • Fits a 35" x 12.50" w/20 x 9 tire and 4.5"-5" back spacing

Premium Quality, Lifetime Warranty and Protection

BDS Suspension manufactures only premium quality suspension products. All are backed by a "No Fine Print" limited lifetime warranty. Guaranteeing all products to be free from defects in material and workmanship to the original retail purchaser. If you break it, they replace it...period.

Drivetrain Protection - BDS Suspension offers FREE 560Plus Factory Protection Plus. This supplemental drivetrain protection (5 years - 60,000 / 100,000 miles) on select vehicles gives you piece of mind with your purchase.  Click here for more info

Important Notes1. Larger tires on stock wheels are not recommended due to brakeline clearance required. Use recommended specifications listed in tire and wheel fitment section.
2. Track bar mounting hardware requires torque spec of 405 ft-lbs .
Vehicle Fitment
ModelF250, F350
Year Fitment2019, 2018, 2017
Tech Specs
ManufacturerBDS Suspension
Manufacturer Part Number1543FPE
Item Numberbds_1543fpe
Product LineLift Kits
Lift Height2 inch
